Terasaki Combination RCD Circuit Breaker RCBO 1P+ N 40 Amp 240V AC 6 kA 1Module 18mm DIN 35 Rail

$Terasaki\Terasaki_DSRCBH64030A.jpg$

Description

Residual Current Device, 240 Volt, 40 Amp, 50/60 Hz, 6 kA Interrupt Capacity, 30 mA Trip Sensitivity, C Curve, 1 + N Pole, 1 Module 18 mm, 1-16 sq-mm/1-25 sq-mm Flexible/1-25 sq-mm/1-35 sq-mm Rigid Terminal, Pin/Fork Connection, IP20/40, DIN Rail Mounting, 5 to 55 deg C, 125 mm Height, 18 mm Width, 76 mm Depth

Key Specifications

SKU	TERDSRCBH64030A
Brand	Terasaki
Range Name	Din-Safe

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	C curve for general light, power and motor starting applications 30 mA sensitivity for general personnel protection applications Single screw RCBO features a neutral pigtail saving cable and installation time Pad lockable and sealable toggle restricts unauthorized action Fast connection pin/fork bus bar comb or NC or GB bus bar chassis Suits metal load centres and Concept range of panel boards
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	DSRCBH64030A-NLA
Current	40 Amp
Connection Type	Pin/Fork
Depth	76 mm
Height	125 mm
Frequency	50/60 Hz
IP Rating	IP20/40
Interrupt Capacity	6 kA
Modules	1 Module 18 mm
Mounting Method	DIN Rail
Number Of Poles	1 Pole
Terminal Connection	1-16 sq-mm / 1-25 sq-mm Flexible / 1-25 sq-mm / 1-35 sq-mm Rigid
Temperature	5 to 55 deg C
Trip Characteristic	C Curve
Voltage	240 Volt
Trip Sensitivity	30 mA
Width	18 mm
