Terasaki Moulded Case Circuit Breaker Thermal Magnetic 1 Pole 25 kA Icu 19 kA Ics 125 Amp
Loading...
Description
Moulded Case Circuit Breaker, 240 Volt AC, 125 Amp, 50/60 Hz, Interrupt Capacity: 25 kA Icu 19 kA Ics, Number of Poles: 1, Thermal Setting: 125 Amp Fixed, Magnetic Setting: 1250 Amp Fixed, 250 AF Frame, Thermal Magnetic Trip, Front, 165mm Height x 35mm Width x 68mm Depth
Key Specifications
| SKU |
TERS160NF1125
|
|---|---|
| Brand |
Terasaki
|
| Range Name |
TemBreak 2 S160NF
|
| Product Type |
MCCBs
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | S160NF1125 |
| Current | 125 Amp |
| Depth | 68 mm |
| Frame Type | 250 AF |
| Frequency | 50/60 Hz |
| Height | 165 mm |
| Interrupt Capacity | 25 kA Icu / 19 kA Ics |
| Magnetic Setting | 1250 Amp Fixed |
| Mounting Method | Front |
| Number Of Poles | 1 Pole |
| Thermal Setting | 125 Amp Fixed |
| Trip Type | Thermal Magnetic |
| Voltage | 240 Volt |
| Width | 35 mm |
