Panduit Locking Forked Spade Insulated Single Grip 1.5-2.5mm M4 Stud Blue 24.6mm OAL

Description

Locking Forked Spade Terminal, Insulated, Single Grip, Conductor Size: 1.5-2.5 mm, Stud Size: M4, Terminal Type: Spring, Snap, 600 Volt Maximum, Wire Strip Length: 7.9mm, Barrel Type: Bevelled, Serrated, Seam Type: Butted, Mounting Method: Free Hanging, Body Material: Copper, Conductive Material: Copper, Insulation Material: Vinyl, Blue Insulation, Tin Plated Finish, 221 deg F, 24.6mm Overall Length, 12.3mm Lug Length, 7.4mm Lug Width, 0.8mm Lug Thickness, 4.06mm Lug Inside Width, Barrel Length: 12.3mm, Max. Insulation Diameter: 4.3mm, 50 Pack

Key Specifications

SKU	PANEV14-8LFB-L
Brand	Panduit
Range Name	StrongHold
Product Type	Forked & Ring Terminals

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	50
UNSPSC Class	39121400
UOM	EA
Vendor Product	EV14-8LFB-L
Barrel Length	12.3 mm
Body Material	Copper
Barrel Type	Bevelled/Serrated
Conductive Material	Copper
Conductor Size	1.5-2.5mm
Finish	Tin Plated
Insulation Colour	Blue
Insulation Material	Vinyl
Insulation Diameter	4.3 mm
Lug Inside Width	4.06 mm
Lug Length	12.3 mm
Lug Width	7.4 mm
Lug Thickness	0.8 mm
Mounting Method	Free Hanging
Overall Length	24.6 mm
Pack Size	50 Pack
Seam Type	Butted
Stud Size	M4 Stud
Temperature	221 deg F
Terminal Type	Spring/Snap
Voltage Rating	600 Volt
Wire Strip Length	7.9 mm
