Swe-Check European Bottle Fuse Link Diazed Slow Acting 20A 500VAC 50kA 500VDC 8kA 13.2x50mm

chevron-left
loader
Loading...

Description

chevron-down
European Bottle Fuse Link Diazed Slow Acting, AC Voltage: 500 VAC, DC Voltage: 500 VDC, 20 Amp, AC Interrupt Capacity: 50 kA, DC Interrupt Capacity: 8 kA, Class TDZ/gG, Blue, 12mm Cap Diameter, 13.2mm Diameter x 50mm Length, DIN Size DI

Key Specifications

chevron-down
SKU
SWE-B16-SB020
Brand
Swe-Check
Range Name
Type TDZ
Product Type
Fuse Links

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • Blown fuse visual indicator
Standard Pack Size 1
UNSPSC Class 39121600
UOM EA
Vendor Product SWE-B16-SB020
AC Interrupt Capacity 50 kA
AC Voltage 500 Volt AC
Cap Diameter 12 mm
Colour Blue
Current 20 Amp
DC Interrupt Capacity 8 kA
DC Voltage 500 Volt DC
Dimensions 13.2 mm Diameter x 50 mm Length
Standard Reference DIN Size DI
Utilisation Category Class TDZ/gG
