APEC Instrumentation Cable Armoured 4 Pair Individually & Overall Screened 0.5mm 110/150V PVC/SWA/PVC Black

Description

Instrumentation Cable Armoured, 0.5 mm, Annealed Copper, 110-150 Volt, 4 Pair, 7/0.3 mm Strands, Individual & Overall Screened Screen, 14.6 mm Overall Diameter, 0.4 mm Insulation Thickness, Steel Wire Armour, Black/White Numerals Core, V-90 PVC Insulation, 5V-90 PVC Sheath, Black Sheath, UL 2464 AS 1125

Key Specifications

Barcode (EAN-13)	932666301750
SKU	APEINSVIOS005P04B
Brand	APEC
Product Type	Instrumentation Cable Armoured

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	26121600
UOM	MTR
Vendor Product	INSVIOS005P04B
Armour Material	Steel Wire
Conductor Size	0.5 mm
Core Colours	Black/White Numerals
Conductor Type	Annealed Copper
Insulation Material	V-90 PVC
Insulation Thickness	0.4 mm
Number of Pairs	4 Pair
Overall Diameter	14.6 mm
Screen Format	Individual & Overall Screened
Sheath Colour	Black
Sheath Material	5V-90 PVC
Standards	UL 2464 AS 1125
Stranding	7/0.3 mm
Voltage	110-150 Volt
