Panduit Locking Forked Spade Insulated Single Grip 1.5-2.5mm M3.5 Stud Blue 22.9mm OAL

Description

Locking Forked Spade Terminal, Insulated, Single Grip, Conductor Size: 1.5-2.5 mm, Stud Size: M3.5, Terminal Type: Spring, Snap, 600 Volt Maximum, Wire Strip Length: 7.9mm, Barrel Type: Bevelled, Serrated, Seam Type: Butted, Mounting Method: Free Hanging, Body Material: Copper, Conductive Material: Copper, Insulation Material: Vinyl, Blue Insulation, Tin Plated Finish, 221 deg F, 22.9mm Overall Length, 11.4mm Lug Length, 6.4mm Lug Width, 0.8mm Lug Thickness, 3.56mm Lug Inside Width, Barrel Length: 11.4mm, Max. Insulation Diameter: 4.3mm, 50 Pack

Key Specifications

SKU	PANEV14-6LFB-L
Brand	Panduit
Range Name	StrongHold
Product Type	Forked & Ring Terminals

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	50
UNSPSC Class	39121400
UOM	EA
Vendor Product	EV14-6LFB-L
Barrel Length	11.4 mm
Barrel Type	Bevelled/Serrated
Conductive Material	Copper
Body Material	Copper
Conductor Size	1.5-2.5mm
Finish	Tin Plated
Insulation Diameter	4.3 mm
Insulation Colour	Blue
Insulation Material	Vinyl
Lug Inside Width	3.56 mm
Lug Length	11.4 mm
Lug Thickness	0.8 mm
Lug Width	6.4 mm
Pack Size	50 Pack
Mounting Method	Free Hanging
Overall Length	22.9 mm
Seam Type	Butted
Stud Size	M3.5 Stud
Temperature	221 deg F
Terminal Type	Spring/Snap
Voltage Rating	600 Volt
Wire Strip Length	7.9 mm
