Schneider Contactor General Purpose AC Operated 3 Pole 11kW 25A AC3 40A AC1 250V 1NO-1NC Auxilary DIN Rail/Plate Mount

Description

General Purpose AC Operated Contactor, 240 Volt AC Coil Voltage, 690 Volt AC/300 Volt DC Contact Voltage, 1 Normally Opened/1 Normally Closed Aux Configuration, 11 kW AC3 AC3 Rating, 25 Amp AC3 AC3 Rating, 40 Amp AC1 AC1 Rating, 3 Pole, 12-22 ms Closing/4-19 ms Opening Operating Time, Screw/Clamp Terminal, DIN Rail/Plate Mounting, IP20, -40 to 60 deg C, 85 mm Height, 45 mm Width, 92 mm Depth

Key Specifications

Barcode (EAN-13)	3389110350081
SKU	TEELC1-D25U7
Brand	Schneider
Range Name	TeSys Model D
Product Type	Contactors General

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121500
UOM	EA
Vendor Product	LC1D25U7
AC1 Rating (Amps)	40 Amp AC1
AC3 Rating (Amps)	25 Amp AC3
AC3 Rating (kW)	11 kW AC3
Contact Voltage	690 Volt AC/300 Volt DC
Contact Configuration	1 Normally Opened/1 Normally Closed Aux
Depth	92 mm
Height	85 mm
IP Rating	IP20
Mounting Method	DIN Rail/Plate
Number Of Poles	3 Pole
Operating Coil Voltage	240 Volt AC
Operating Time	12-22 ms Closing/4-19 ms Opening
Temperature	-40 to 60 deg C
Terminal Connection	Screw/Clamp
Width	45 mm
