IDEC Miniature General Purpose Relay Plug-In Mount 1P SPDT 10A 12VDC 5 Pin Flat

Description

Miniature General Purpose Relay, 240 Volt AC, 12 Volt DC, 10 Amp, 0.8 Watt, 5 Pin Flat, 1 Pole, SPDT/1CO, 188 Ohm, Operating Time: 20 Operate/Release ms, Plug-In Mount, Silver Cadmium Oxide/Cadmium Free (Ag-alloy), -25 to 50 deg C, 27.5 mm Height, 42 mm Width, 14 mm Depth

Key Specifications

Barcode (EAN-13)	9322017188115
SKU	IDCRH1B-UDC12
Brand	IDEC
Range Name	RH Series
Product Type	Power Relays

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Compact midget size saves space High switching capacity Without LED
Standard Pack Size	1
UNSPSC Class	39122300
UOM	EA
Vendor Product	RH1B-UDC12
Contact Configuration	SPDT/1 Changeover
Depth	14 mm
Height	27.5 mm
Current	10 Amp
Mounting Method	Plug In
Contact Material	Silver Cadmium Oxide/Cadmium Free (Ag-alloy)
Number Of Poles	1 Pole
Operating Coil Voltage	12 Volt DC
Pin Configuration	5 Pin Flat
Operating Time	20 Operate/Release ms
Power Rating	0.8 Watt
Resistance	188 Ohm
Temperature	-25 to 50 deg C
Voltage	240 Volt AC
Width	42 mm
