Clipsal Socket Outlet Surface Mounting RCD Protected 3Ph 20A 500V 5 Pin Round 30mA Grey IP66

Description

Socket Outlet RCD Protected, 500 Volt, 20 Amp AC1, 3 Phase Phase, 5 Pole, 3 Gang, 5 Pin Round, 30 mA Trip Sensitivity, Screw Connection, 1.5-16 mm Terminal Capacity, Surface Mounting, IP66, Polycarbonate, Grey, -25 to 75 deg C, 294 mm Height, 110 mm Width, 101 mm Depth

Key Specifications

Barcode (EAN-13)	9311554277048
SKU	CLI56C520RCGY
Brand	Clipsal
Range Name	56 Series
Product Type	Socket Outlets RCD Protected

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39122200
UOM	EA
Vendor Product	56C520RC-GY
Colour	Grey
Connection Type	Screw
Depth	101 mm
Height	294 mm
Number Of Gangs	3 Gang
Material	Polycarbonate
IP Rating	IP66
Mounting Method	Surface
Number Of Poles	5 Pole
Phase	3 Phase
Pin Configuration	5 Pin Round
Temperature	-25 to 75 deg C
Width	110 mm
Voltage	500 Volt
Terminal Capacity	1.5-16 mm
Trip Sensitivity	30 mA
