CMP Products Flame Proof Cable Gland Armoured 40.4-53.1mm M50 IP66

Description

Flame Proof Cable Gland, Armoured, M50, 15 mm Thread Length, 40.4 mm Min. Sheath OD, 53.1 mm Max. Sheath OD, 44.1 mm Max. Bedding OD, 2 mm Min. Armour Wire, 2.5 mm Max. Armour Wire, Exd IIC, Exe II, Ex nR II, Ex tD A21 IP66, Exd I, Exe I, 70 mm Width Across Flats, 78.6 mm Width Across Corners, 80.5 mm Protrusion Length, IP66, Thermoset Elastomer Seal, Brass Body, Nickel Plated Finish, -60 to 130 deg C

Key Specifications

SKU	CMP50E1FW1RA5
Brand	CMP Products
Range Name	Type E1FW
Product Type	Cable Glands Hazardous Area

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Metal-to-metal armour clamping Direct and remote installation Displacement type flameproof inner seal Controlled outer load retention seal Unique OSTG prevents overtightening Designed to prevent cold flow EMC tested
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	50E1FW1RA5
Body Material	Brass
Finish	Nickel Plated
Hazardous Area Rating	Exd IIC Exe II Ex nR II Ex tD A21 IP66 Exd I Exe I
IP Rating	IP66
Max. Armour Wire	2.5 mm
Max. Bedding OD	44.1 mm
Min. Armour Wire	2 mm
Max. Sheath OD	53.1 mm
Min. Sheath OD	40.4 mm
Protrusion Length	80.5 mm
Temperature	-60 to 130 deg C
Seal Material	Thermoset Elastomer
Thread Size	M50
Thread Length	15 mm
Width Across Corners	78.6 mm
Width Across Flats	70 mm
