Tycab Automotive Cable Battery & Starter 1 Core 0 AWG V90 PVC Red
Loading...
Description
Automotive Cable, Battery & Starter, 1 Core, 49 mm, 0 AWG, Oxygen Free Plain Copper, 246 Amp, 608/0.32 mm Strands, 12.7 mm Overall Diameter, 1.7 mm Insulation Thickness, 0.4 Ohm/km Conductor Resistance, V-90 PVC Insulation, Red Insulation, 30 to 70 deg C
Key Specifications
| Barcode (EAN-13) |
9320943006268
|
|---|---|
| SKU |
TYCABC1612032-RD-30
|
| Brand |
Tycab
|
| Product Type |
Automotive Cable Battery & Starter
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 30 |
|---|---|
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | ABC1612032-RD-30 |
| Conductor Resistance | 0.4 Ohm/km |
| Conductor Size | 49 mm |
| Conductor Size (mm) | 0 AWG |
| Conductor Type | Oxygen Free Copper |
| Current | 246 Amp |
| Insulation Colour | Red |
| Insulation Material | V-90 PVC |
| Insulation Thickness | 1.7 mm |
| Number of Cores | 1 Core |
| Overall Diameter | 12.7 mm |
| Temperature | 30 to 70 deg C |
| Stranding | 608/0.32 mm |
