Cabac Quick Connect Male Fully Insulated Double Grip 0.5-1.6mm 6.4/0.8mm Tab Red PVC

$Cabac\Cabac_FIMT125__64DG.jpg$

Description

QC Terminal Male Fully Insulated Double Grip, 0.5-1.6 mm, 300 Volt, 1.5 kV Min. Breakdown Voltage, 6.4 x 0.8 mm Tab Size, 200 Mpa Tensile Strength, 35% Ductile Rating, Copper, PVC Insulation, Red Insulation, 100 micro-Ohm Insulation Resistance, Tin Electroplated, -40 to 105 deg C, 50 Pack

Key Specifications

Barcode (EAN-13)	9318674604358
SKU	CAAFIMT1.25-6.4DG
Brand	Cabac
Range Name	Pre-Insulated Terminals
Product Type	Quick Connect Terminals

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Double grip - high quality product meeting many international standards Reduce installation errors - full insulation Superior long term electrical integrity
Standard Pack Size	50
UNSPSC Class	39121400
UOM	EA
Vendor Product	FIMT1.25-6.4DG
Conductive Material	Copper
Conductor Size	0.5-1.6mm
Ductile Rating	35%
Finish	Tin Electroplated
Insulation Material	PVC
Insulation Colour	Red
Insulation Resistance	100 micro-Ohm
Min. Breakdown Voltage	1.5 kV
Pack Size	50 Pack
Tab Size	6.4 x 0.8 mm
Temperature	-40 to 105 deg C
Tensile Strength	200 MPa
Voltage Rating	300 Volt
