Helukabel JZ-500 Flexible Control Cable Unscreened 6 Core & Earth 4mm 0.3/0.5kV Copper PVC/PVC Grey

Description

Flexible Control Cable, 4 mm, Bare Copper, 0.3-0.5 kV, 6 Core + Earth, 13.4 mm Overall Diameter, Static 53.6 mm Flexible 100.5 mm Bend Radius, 20 MOhm/km Insulation Resistance, Black/Green/Yellow/White Numerals Core, PVC Insulation, PVC Sheath, Grey Sheath, Static -40 to 80 deg C Flexible -15 to 80 deg C, DIN VDE 0285-525-2-51 DIN EN 50525-2-51

Key Specifications

SKU	DKSCC7G4
Brand	Helukabel
Product Type	Flexible Control Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Flame retardant UV resistant Submersible to 500 metres Oil resistant Tinned conductors
Standard Pack Size	1
UNSPSC Class	26121600
UOM	MTR
Vendor Product	CC7G4
Bend Radius	Static 53.6 mm/Flexible 100.5 mm
Core Colours	Black/Green/Yellow/White Numerals
Conductor Size	4 mm
Conductor Type	Bare Copper
Insulation Material	PVC
Insulation Resistance	20 Mohm/km
Number of Cores	6 Core + Earth
Overall Diameter	13.4 mm
Sheath Colour	Grey
Sheath Material	PVC
Standards	DIN VDE 0285-525-2-51 DIN EN 50525-2-51
Temperature	Static -40 to 80 deg C Flexible -15 to 80 deg C
Voltage	0.3-0.5 kV
