Legrand Mains Isolating Switch 3P 100A 400V 2C/O Busbar DIN Rail Mount

Description

Mains Isolating Switch, 400 V, 100 Amp, 50/60 Hz, 3 Poles, 3 Modules, 53.1mm Module Width, 2C/O, 4-35 mm Flexible, 4-50 mm Rigid Conductor, Busbar, IP20, DIN Rail, Plastic, Grey Handle,-25 to 70 deg C, 94.8mm Height x 70.2mm Depth

Key Specifications

Barcode (EAN-13)	3245064064699
SKU	LEG406469
Brand	Legrand
Range Name	Lexic DX3
Product Type	Mains Switches

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121300
UOM	EA
Vendor Product	406469
Contact Configuration	2 Changeover
Colour	Grey Handle
Conductor Size	4-35 sq-mm Flexible/4-50 sq-mm Rigid
Dimensions	94.8mm Height x 70.2mm Depth
Connection Type	Busbar
Current	100 Amp
Frequency	50/60 Hz
IP Rating	IP20
Material	Plastic
Mounting Method	DIN Rail
Number Of Poles	3 Pole
Modules	3 Module 53.1mm
Temperature	-25 to 70 deg C
Voltage	400 Volt
