NHP DIN-T Miniature Circuit Breaker C Curve 440V 16A 10kA 2Pole 2Module 35mm DIN Rail Mount

$NHP_DIN-T\NHP_DIN-T_MCB_DC_10kA_1P.JPG$

Description

Suitable for panelboards with DC compatible busbar chassis (2P). Red/green contact position indicator that is independent of the toggle position. Inbuilt permanent magnet to ensure quick arc extinguishing. Quick install into Concept distribution panelboards.

Key Specifications

Barcode (EAN-13)	4053546150308
SKU	NHPDTMDC216C
Brand	NHP DIN-T
Product Type	Mini Circuit Breakers

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	DTMDC216C
Actuator Type	Toggle
Cable Size	0.75-35 sq-mm (Solid-core) / 0.75 sq-mm (Multi-wired)
Colour	Grey
Current	16 Amp
Depth	75.8 mm
Frequency	50/60 Hz
Height	85 mm
Interrupt Capacity	10 kA
IP Rating	IP40
Modules	2 Module 35 mm
Mounting Method	DIN Rail
Number Of Poles	2 Pole
Temperature	-25 to 70 deg C
Voltage	440 Volt AC / 440 Volt DC
Width	35 mm
