Panduit Quick Connect Male Insulated Double Grip 0.5-1mm 6.3mm Tab Red Nylon

$Panduit\Panduit_EDNF18250FIMB-Q.jpg$

Description

QC Terminal, male, Insulated, Double Grip, Conductor Size: 0.5-1 mm, Tab Size: 6.3mm, Wire Strip Length: 7.1mm, Seam Type: Butted, 600 Volt Maximum, Flammability: HB, Crimping Die: CT-520CT-600-ACT-1525CT-2500, Mounting Method: Free Hanging, Base Material: Brass, Conductive Material: Copper, Insulation Material: Nylon, Red Insulation, Tin Plated Finish, 125 deg C, Max. Wire Insulation Diameter: 3.4mm, 21.3mm Length, 11.4mm Width, Height: 5.6mm, Thickness: 0.4mm, 25 Pack

Key Specifications

SKU	PANEDNF18250FIMB-Q
Brand	Panduit
Range Name	StrongHold
Product Type	Quick Connect Terminals

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	25
UNSPSC Class	39121400
UOM	EA
Vendor Product	EDNF18250FIMB-Q
Base Material	Brass
Conductive Material	Copper
Conductor Size	0.5-1mm
Crimping Die	CT-520CT-600-ACT-1525CT-2500
Finish	Tin Plated
Height	5.6 mm
Insulation Material	Nylon
Insulation Colour	Red
Mounting Method	Free Hanging
Pack Size	25 Pack
Seam Type	Butted
Tab Size	6.3 mm
Temperature	125 deg C
Thickness	0.4 mm
Voltage Rating	600 Volt
Width	11.4 mm
Wire Insulation Diameter	3.4 mm
Wire Strip Length	7.1 mm
