Panduit Ring Terminal Insulated Single Grip 0.5-1mm M5 Stud Red 23.9mm OAL

$Panduit\Panduit_EV18-10RB-Q.jpg$

Description

Ring Terminal, Insulated, Single Grip, Conductor Size: 0.5-1 mm, Stud Size: M5, Terminal Type: Circular, 600 Volt Maximum, Wire Strip Length: 7.9mm, Barrel Type: Funnel, Seam Type: Butted, Mounting Method: Free Hanging, Body Material: Copper, Conductive Material: Copper, Insulation Material: Vinyl, Red Insulation, Tin Plated Finish, 221 deg F, 23.9mm Overall Length, 11.9mm Lug Length, 7.9mm Lug Width, 0.8mm Lug Thickness, 5.1mm Lug Inside Diameter, Barrel Length: 9.9mm, Max. Insulation Diameter: 3.8mm, 25 Pack

Key Specifications

SKU	PANEV18-10RB-Q
Brand	Panduit
Range Name	StrongHold
Product Type	Forked & Ring Terminals

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	25
UNSPSC Class	39121400
UOM	EA
Vendor Product	EV18-10RB-Q
Body Material	Copper
Barrel Length	9.9 mm
Barrel Type	Funnel
Conductor Size	0.5-1mm
Conductive Material	Copper
Insulation Diameter	3.8 mm
Insulation Colour	Red
Finish	Tin Plated
Insulation Material	Vinyl
Lug Thickness	0.8 mm
Lug Inside Diameter	5.1 mm
Lug Length	11.9 mm
Lug Width	7.9 mm
Mounting Method	Free Hanging
Overall Length	23.9 mm
Pack Size	25 Pack
Temperature	221 deg F
Stud Size	M5 Stud
Seam Type	Butted
Terminal Type	Circular
Voltage Rating	600 Volt
Wire Strip Length	7.9 mm
