Sprecher+Schuh Contactor Kit Power AC/DC Operated 75 kW 146/60A 250-500VAC/DC 1NO+1NC 3P IP00 Screw Mount

$Sprecher\Sprecher_CA914611480WKIT.jpg$

Description

The Sprecher + Schuh CA9 contactors are designed with a smaller footprint and are ideal for harsh environments such as steel mills, rock quarries, mines or for large power applications where a sturdy, durable contactor is required. Combining the basic functionality of the CA7 series and the rugged performance demanded in this larger horsepower range, they are guaranteed to increase productivity

Key Specifications

SKU	S&SCA914611480WKIT
Brand	Sprecher+Schuh
Range Name	CA9

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121500
UOM	EA
Vendor Product	CA914611480WKIT
AC1 Rating (Amps)	225 Amp AC1
AC3 Rating (Amps)	146 / 60 Amp AC3
AC3 Rating (kW)	75 kW
Contact Configuration	1 Normally Opened & 1 Normally Closed
Contact Voltage	400 / 1000 Volt
Control Circuit Voltage	250-500 Volt AC/DC
Depth	126 mm
Height	150 mm
IP Rating	IP00
Mounting Method	Screw
Number Of Poles	3 Pole
Operating Coil Voltage	250-500 Volt AC/DC
Temperature	-40 to 70 deg C
Terminal Connection	Bolt
Width	90 mm
