Schneider Circuit Breaker Motor Rated 3Pole 25A 11kW 690VAC DIN Rail Clipped Mount

Description

Motor Rated Miniature Circuit Breaker, 690 Volt, 25 Amp, 50/60 Hz, 15 kA Interrupt Capacity, 327 Magnetic Rating, 11 kW, 3 Pole, Pushbutton Operator, Screw Clamp Terminal, 100000 Cycles, IP20, DIN Rail Mounting, 20 to 60 deg C, 89 mm Height, 45 mm Width, 78.5 mm Depth

Key Specifications

Barcode (EAN-13)	3389110343250
SKU	TEEGV2ME22
Brand	Schneider
Range Name	GV2ME
Product Type	Mini Circuit Breakers

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	GV2ME22
Current	25 Amp
Height	89 mm
Frequency	50/60 Hz
Depth	78.5 mm
Interrupt Capacity	15 kA
Load Rating	11 kW
IP Rating	IP20
Magnetic Rating	327
Mounting Method	DIN Rail
Operating Cycles	100000 Cycles
Number Of Poles	3 Pole
Operator Type	Operators
Terminal Type	Screw Clamp
Voltage	690 Volt
Temperature	20 to 60 deg C
Width	45 mm
