Clipsal Time Delay Relay Analogue DIN Rail Mount 1CO Off Delay 0.1s-100Hr 24VDC/24-240V

$Clipsal\Clipsal_RE17RCMU.jpg$

Description

Time Delay Relay Analogue, 24 Volt DC/24-240 Volt AC, 8 Amp, 0-32 VA at 240 Volt AC, 0.6 Watt at 24 Volt DC, 1CO, Timing Function: Off Delay, Timing Range: 0.1 sec-100 hr, Selector Switch Front Panel, 100000 Electrical, 10000000 Mechanical Cycles, 20 to 12 AWG Solid, 24 to 14 AWG Flexible, Tightening Torque: 0.6-1 N/m, Screw Terminal, DIN Rail Mount, IP20, IP40, IP50, Cadmium Free, -20 to 60 deg C, 90 mm Height, 17.5 mm Width, 72 mm Depth

Key Specifications

Barcode (EAN-13)	3606480552694
SKU	TEERE17RCMU
Brand	Clipsal
Product Type	Time Delay Relays

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39122300
UOM	EA
Vendor Product	RE17RCMU
IP Rating	IP20/40/50
Voltage	24-240 Volt AC/24 Volt DC
Conductor Size	20 to 12 AWG Solid/24 to 14 AWG Flexible
Contact Configuration	1 Changeover
Control Type	Selector Switch Front Panel
Timing Range	0.1 Second-100 Hours
Timing Function	Off Delay
Height	90 mm
Width	17.5 mm
Terminal Connection	Screw
Current	8 Amp
Depth	72 mm
Power Rating	0-32 VA @ 240 Volt AC/0.6 Watt @ 24 Volt DC
Temperature	-20 to 60 deg C
Mounting Method	DIN Rail
Operating Cycles	100000 Electrical/10000000 Mechanical Cycles
Tightening Torque	0.6-1 N/m
