Terasaki Combination RCD Circuit Breaker RCBO 1P+ N 10 Amp 240V AC 6 kA 1Module 25mm Clip Tray
Loading...
Description
Combination RCD Circuit Breaker RCBO, 10 Amp, 240 Volt AC, 50/60 Hz, Interrupt Capacity: 6 kA, Trip Sensitivity: 30 mA, Number of Poles: 1P + N, Number of Modules: 1, 25mm Module Width, Clip Tray,-25 to 55 deg C, 110mm Height, 25mm Width, 60mm Depth
Key Specifications
| Barcode (EAN-13) |
9321807156457
|
|---|---|
| SKU |
TERSRCB1030
|
| Brand |
Terasaki
|
| Range Name |
Safe-T
|
| Product Type |
Combination RCBO
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | SRCB1030 |
| Current | 10 Amp |
| Depth | 60 mm |
| Height | 110 mm |
| Frequency | 50/60 Hz |
| Interrupt Capacity | 6 kA |
| Modules | 1 Module 25 mm |
| Mounting Method | Clip Tray |
| Number Of Poles | 1 Pole |
| Temperature | -25 to 55 deg C |
| Voltage | 240 Volt |
| Trip Sensitivity | 30 mA |
| Width | 25 mm |
